Electric Scissor LiftsCompact 8W

  • Electric Scissor Lifts
  • Electric
  • Flat ground
  • Indoor and outdoor use
  • Logistic / Retail / Industry
  • Finishings
  • Maintenance & restoration
  • Sporting & other events
  • Exceptional productivity
  • Load capacity up to 450 kg (C 8 W and C 10)
  • Driveable at full height
  • Both inside and outside use with the same load capacity
  • Extended platform
  • Width of 1.2 m
  • Robust, reliable, easy to maintain
  • Long working cycles

Working height 8.27 m
Platform height 6.27 m
Platform length - outside 2.31 m
Platform length - extended 3.23 m
Length - extension 0.92 m
Platform width - outside 1.2 m
Storage height 1.28 m
Height - stowed 2.14 m
Overall width 1.2 m
Length 2.49 m
Wheelbase 1.86 m
Ground clearance - center 13 cm
Ground clearance - deployed potholes 2.5 cm
Drive speed 0.8 - 3.2 km/h
Maximum drive height 6.27 m
Gradeability 23 %
Tilt 3 °
Turning radius - outside 2.5 m
Non-marking tyres 15 x 5
Batteries 24 V - 340 Ah
Hydraulic system capacity 25 l
Weight 2 030 kg
Lift capacity - inside 450 kg (3 pers.)
Lift capacity - outside 450 kg (3 pers.)
Lift capacity on the extension deck 150 kg
  • 2 front steering & driving wheels
  • Solid non-marking tyres
  • Free wheeling device
  • Removable control box in platform
  • Proportional lift and drive
  • Load Management System in the platform
  • Tilt controller
  • Swing out component tray
  • Horn
  • Hourmeter
  • 24 V DC motor
  • Battery charger with automatic stop
  • Battery charge indicator
  • Manual platform lowering valve
  • Towing hooks
  • Pothole guards
  • Integrated forklift pockets
  • Power to platform
  • Biodegradable hydraulic oil
  • Traction batteries
  • Maintenance-free batteries
  • Centralised battery filling
  • Travel alarm (standard in AUS / NZ)
  • Flashing light (standard in AUS / NZ)
  • Working light
  • Folding guardrails (standard in AUS / NZ)
