Presentation
- Smart rugged design
- Maximized potential
- Unique user experience
- Unbeatable serviceability
Specifications
| Lift capacity - inside | 450 kg (3 pers.) |
| Lift capacity - outside | 450 kg (1 pers.) |
| Lift capacity on the extension deck | 120 kg |
| Platform length - outside | 2.4 m |
| Platform length - extended | 3.32 m |
| Length - extension | 0.92 m |
| Platform width - outside | 1.17 m |
| Height - stowed | 2.35 m |
| Guardrails lowered | 1.65 m |
| Overall width | 1.20 m |
| Length | 2.5 m |
| Wheelbase | 1.86 m |
| Ground clearance - center | 12.5 cm |
| Ground clearance - deployed potholes | 2 cm |
| Drive speed | 0.7 / 1.5 / 4.2 km/h |
| Gradeability | 25 % |
| Tilt (lonitudinal / lateral) | 3.5° / 1.5° |
| Turning radius - outside | 1.83 m |
| Non-marking tyres | 15 x 5 |
| Batteries | 24 V - 225 Ah (C20) |
| Hydraulic system capacity | 10 l |
| Weight | 2 490 kg |
| Working height - indoor | 10 m |
| Working height - outdoor | 10 m |
| Platform height - indoor | 8 m |
| Platform height - outdoor | 8 m |
| Max. drive working height - indoor | 10 m |
| Max. drive working height - outdoor | 10 m |
| Working height - indoor | 10 m |
| Working height - outdoor | 10 m |
| Platform height - indoor | 8 m |
| Platform height - outdoor | 8 m |
| Max. drive working height - indoor | 10 m |
| Max. drive working height - outdoor | 10 m |
- Haulotte Activ'Screen: on-board diagnostic and setting screen
- Haulotte Activ'Energy Management: Smart CAN charger with manual battery water filling system
- Versatile use : outdoor/ indoor
- Foldable guardrails
- Front platform extension
- AC motors
- 27A multivoltage charger
- Mobile pothole guards
- Battery access with swing out tray
- Lateral & longitudinal forklift pockets
- Motion alarm
- Single flashing light
- 2 front steering wheels, 2 rear drive wheels
- Solid non marking tires
- Haulotte Activ'Energy Management: automatic battery water filling systems
- Secondary guarding system
- Telematics solutions
- AGM maintenance-free batteries
- Pipe cradle
- Panel carrier
- Additional protection of upper & lower control box
- Working light
- Flashing light (dual or 360°)
- Biodegradable hydraulic oil
- Cold weather hydraulic oil
