Specifications
Smart rugged design
- Impact-proof counterweight with with integrated ladder protection, AC motors and charger plug
- Reinforced guardrails with additional vertical stile for maximum durability
Maximized potential
- Access all worksites: foldable guardrails, lateral & longitudinal forklift pockets
- IN/OUT usage with full height driving and no load restriction
Unique user experience
- Proportional movements for precise driving (AC motors)
- Ergonomic upper control box with grab handle & speed selector
Unbeatable serviceability
- Haulotte Activ'Energy Management for battery care
- On-board & remote settings and diagnostic tools with Haulotte Diag, Haulotte Activ’Screen and Sherpal telematics solution
| Working height | 11.75 m |
| Platform height | 9.75 m |
| Max. drive working height | 9.75 m |
| Lift capacity - inside | 320 kg (3 pers.) |
| Lift capacity - outside | 320 kg (1 pers.) |
| Lift capacity on the extension deck | 120 kg |
| Platform length - outside | 2.4 m |
| Platform length - extended | 3.32 m |
| Length - extension | 0.92 m |
| Platform width - outside | 1.17 m |
| Height - stowed | 2.47 m |
| Guardrails lowered | 1.77 m |
| Overall width | 1.20 m |
| Length | 2.5 m |
| Wheelbase | 1.86 m |
| Ground clearance - center | 12.5 cm |
| Ground clearance - deployed potholes | 2 cm |
| Drive speed | 0.7 /1.5 / 4.2 km/h |
| Gradeability | 25 % |
| Tilt (lonitudinal / lateral) | 3.5° / 1.5° |
| Turning radius - outside | 1.83 m |
| Non-marking tyres | 15 x 5 |
| Batteries | 24 V - 225 Ah (C20) |
| Hydraulic system capacity | 14 l |
| Weight | 2 940 kg |
| Micro drivespeed | 0 km/h |
| Low drivespeed | 0 km/h |
| Micro drivespeed | 0 km/h |
| Low drivespeed | 0 km/h |
| Length of the chassis (without platform) | 0 m |
- Haulotte Activ'Energy Management: Smart CAN charger (without centralized battery watering system)
- 27A multivoltage charger
- Battery access with swing out tray
- Battery level indicator
- Haulotte Activ’Screen (battery charge information, hourmeter, service alerts & failures in code or in text...)
- Lateral & longitudinal forklift pockets
- Foldable guardrails
- Front platform extension
- AC motors
- Mobile upper control box
- 2 drive speeds selector
- Manual emergency descent
- Mobile pothole guards
- MyHaulotte multi-services portal access
- 2 front steering wheels, 2 rear drive wheels
- Solid non marking tires
- Motion alarm
- Electric brake release system
- Drop bar entry
- Haulotte Activ'Energy Management: automatic or manual battery water filling systems
- AGM maintenance-free batteries
- Secondary guarding system
- Telematics solutions
- Pipe cradle
- Panel carrier
- Swing gate entry
- Basket plug (110 / 230 V)
- Additional protection of upper & lower control box
- Working light
- Flashing light (single, dual or 360°)
- Biodegradable hydraulic oil
- Cold weather hydraulic oil
